More Price-Competitive

Conversion proposal from PLC(sequencer) to CPU circuit board enables a product’s large-scale cost reduction in an expensive AD converter and a digital analog converter of AD Converter / a current-voltage converter.

Synergy Effects to accelerate cost reductions

• Changeover from relay-switches to FETs (Enabling longer product life and less expensive maintenance / repaire expense)
• Elimination of control board wiring work
• Large scale reduction of wiring man-hours
• Stabler quality by automatic machine mounting

Down-Sizing

A large-size control panel which mounts a digital analog converter can be down-sized to one PCB assembly.

More Functional

An embedded MPU PCB enables high-speed calculation and process. Margin design of I/O enables much easier functional expansion for external load.

Subject and Requirements

• We want to curtail the total cost by changing a part of common functions into a PC Board.
• We want to reduce the product size by changing into a PC Board.

Solution Idea and Example Cases

To design the optimal circuit in a PC Board from customer’s specification and assist their software development.
